What problems are prone to occur when the cone crusher is not used for a long time

Time：2022-05-15 16:43:28 Share To

　　Cone crusher is the equipment for medium-fine crushing of hard and medium-hard ores. It is widely used in metal mining, met urgy, chemical industry, construction, cement and other industries. It has high processing efficiency and is the key equipment to achieve more crushing and less grinding. After the equipment has been shut down for a long time, various problems may occur after resumption of work. This article briefly analyzes the common problems of cone crushers.

　　1. When the oil circuit in the large cone crusher or the oil pipe of the thin oil lubrication system is blocked, it is easy to cause the oil pressure and oil temperature to rise at the same time (when the oil return pipe is blocked, oil leaks from the water seal and dustproof device, so that there is oil in the water seal drainage. , but the oil pressure does not rise), it is necessary to s* the machine to troubleshoot;

　　2. Part of the eccentric bushing is faulty, when the oil temperature is > 55 °C and the oil pressure does not rise, the machine should be s*ped to eliminate the faults of the straight bushing and the tapered bushing;

　　3. When the filter is blocked, the oil pressure of the front and rear oil pipes is different. If the oil pressure difference is er than 0.04MPa, the oil can be supplied without the filter *, and then the filter can be disassembled and washed, but the oil supply directly to the crusher should be less than 2~3h;

　　4. The oil temperature is low, the oil switch is not turned on properly, and the oil pump is not running properly, there will be no oil flow in the oil quantity indicator. Although the oil pump is running, the oil pressure is less than 0.05MPa. It is necessary to heat the oil, turn on the oil switch, and repair or Replace the oil pump;

　　5. In winter, the oil temperature is too low, the safety valve fails or the oil pumping capacity is too large. When the oil supply pressure is too large, the broken cone will be lifted. The oil should be heated, the safety valve should be adjusted or the oil pump should be replaced;

　　6. If the bearing, bushing, shaft sleeve, bevel gear and other parts are faulty, the ambient temperature is too high, there is no cooling water, the cooling water pressure is low or the cooler is blocked. water, increase the cooling water pressure or clean the cooler.
